Professional Fish Shrimp Pond Paddle Wheel Aerator
1hp Aerator 1hp Fish Farming Aquaculture Aerator Paddle Wheel
Areators Aerating A Pond
Paddle wheel aerators are a popular aeration technology used in
aquaculture to improve dissolved oxygen levels and water quality.
They are often used in large-scale aquaculture operations, such as
fish farms, where oxygen levels can be critical to the survival and
growth of aquatic organisms. In this article, we will discuss what
paddle wheel aerators are, how they work, and their usage in
aquaculture. A paddle wheel aerator is a mechanical device that is
designed to agitate and aerate water in aquaculture ponds. It
consists of a motor-driven paddle wheel that creates a continuous
flow of water, which helps to oxygenate the water and improve water
quality. Paddle wheel aerators are typically powered by
electricity, and they can be used in both freshwater and saltwater
applications.
Feature:
1. adopt the arc beve; gear,instead of a turbine scroll bar,energy
efficient,than traditional machine Energy sacing more than 20%;
2. the arc bevel gear production of chromium manganese titanium
alloy steel manufacture,the surface carbonitriding,high
hardness,Long service life;
3. use of mechanical seal,to ensure no leakage pollution;
4. motor built-in protection device,to avoid accidentally burned
out motor; 5.the overall plastic pontoon,nylon impeller,stainless
steel shaft and bracket.
Name | Paddle wheel aerators |
Application filed | Fish Farming Fish Pond |
Application | Fish Farming Oxygen Increasing |
Material | 201 Stainless Steel |
Motor | Electric Motor |
Power | 0.75kw |
Voltage | 380V |
Function | Increasing Dissolved Oxygen |
Weight | 60kg |
Usage | Fishing Farming Water Paddle Wheel Aerator |
1. High quality motor expertise design for aquaculture industry.
2. Low friction gear reduce with low resistance to decrease energy
losses.
3. Sturdy stainless steel frame ensure without any deformation and
high durability.
4. High performance impeller,replaceable paddle ,low maintenance
cost.
5. HDPE float resist impact,acid-alkalinity and sun exposure. It
can work a long time.
Power | Voltage | Loading Area | Power efficiency(kg02/kwh) | oxygentranster capacity(KgO2/kwh) | Noise db(A) |
0.75kw | 220V | 1-5 | ≥1.25 | ≥1.1 | ≤78 |
0.75kw | 380V | 1-5 | ≥1.25 | ≥1.1 | ≤78 |
1.5kw | 220V | 3-10 | ≥1.25 | ≥1.5 | ≤78 |
1.5kw | 380V | 3-10 | ≥1.25 | ≥1.5 | ≤78 |
2.2kw | 380V | 4-12 | ≥1.5 | ≥2.0 | ≤78 |
1. Motor built-in protection device,when the three-phase power
phase or motor overheating will automatically jump to avoid
accidents,motor burned out;
2. gear using material chromiun manganese titanium alloy
steel,tooth surface after carbonitriding,prolonging the service
life greatly;
3. according to the special requirements of different use of the
environmentand the user,developed engineering plastics and
stainless steel impller,ensure in sea water or industrial corrosive
wasterwater in the long-time use,without frequent replacement of
the impeller or brush paint.
Product application areas
① Application of deep well solar pump to irrigation
② Village and town water supply
③ Clean drinking water
④ Garden watering
⑤ Environment friendly
⑥ Pumping and drip irrigation
FAQ
Q1. Are you a manufacturer or trading company?
A: We are a manufacturer.
Q2. What's your company's main products?
A: Our company is specialized in kinds of aerators for fish pond
and shrimp pond, such as paddlewheel aerator.
Q3. What's the MOQ for your production?
A: NO MOQ.
Q4. What's the lead time?
Usually about 15days-20days, if large quantity, will check the
production line and arrange the schedule.
Q5. What's your payment term?
A: 30% T/T in advance, the rest pay off before delivery.
Q6. Where is your loading port?
A: Ningbo, or else port in China as your requirements.
